Rotary Tedders Common Specifications and Parameters
The cut grass is turned over and spread out, so that the grass is evenly and fluffy spread on the ground, which can quickly dry the grass, so as to shorten the drying time and reduce the loss of grass.
Key features and advantages
- Spring tine arms made of high-quality round tubes
- Spring tines made of high-quality spring steel with different shank lengths
- PTO shaft with safety clutch
- Hydraulic connection: 1 x one-way hydraulic connection (1EW), 1 x one-way hydraulic connection for central wheel shift (1EW)
- Hydraulic folding of rotors
-
Different length of spring tines protect against loss of broken.
-
Equipped with a central wheel shift system. Rotary Tedders are highly productive tedders for heavier grass types Despite its large size and working width the tedder is extremely manoeuvrable and easy to use because most of the settings can be done from the tractor cabin.
Technical data
| Model | DFRT-6 |
|---|---|
| Angle adjustment(°) | 16 ~ 20 |
| Assembly time(h) | 5 |
| Capacity(ha/h) | 6.1 ~ 6.3 |
| Machine width(mm) | 6300 |
| No. of spring tines per arm (machine) | 5 |
| Number of rotors | 6 |
| PTO rotation speed(rpm) | 540 |
| Required tractor power(hp) | 45 |
| Rotation speed(r/min) | 175 |
| Rotor diameter(mm) | 1300 |
| Safety clutch(nm) | 900 |
| Transport height(mm) | 3000 |
| Transport width(mm) | 2800 |
| Tyre size | 16*6.5-8 |
| Weight(Kg) | 740 |
| Working width(mm) | 5900 ~ 6100 |
